Description
Folding shower seat shall have a frame constructed of Type-304, satin-finish stainless steel that consists of 16-gauge (1.6mm),
1-1/4” (30mm) square tubing and 18-gauge (1.2mm), 1” (25mm) diameter seamless tubing. Seat shall be one‐piece, 5/16″
(8mm) thick, solidly fused plastic laminate with matte-finish melamine surfaces, ivory-colored face sheets, and black phenolic-
resin core; secured to frame with stainless steel carriage bolts and acorn nuts. Shower seat shall be equipped with two 3”
(75mm) diameter mounting flanges constructed of Type-304, 3/16” (5mm) thick, satin-finish stainless steel; a guide bracket
constructed of Type-304, 16-gauge (1.6mm), satin-finish stainless steel; and a spring constructed of Type-301, 24-gauge (0.6mm)
stainless steel that is spot-welded to a baseplate of Type-304, heavy-gauge stainless steel. Seat shall be able to lock in upright
position when not in use. Shower seat shall comply with accessible design guidelines (including ADAAG in the U.S.A.).
