Bobrick Duraline CGL Color Options
Bobrick Duraline Series Durability Performance Chart
Scratch Resistance of the Bobrick Duraline SeriesCompact Laminate Partition
Impact Resistance of Bobrick Duraline Series Partition
Waterproof Durability of Bobrick Duraline Series Toilet Partitions
Color swatches displaying the available finish options for Bobrick Duraline Series Compact Grade Laminate material.
Performance chart comparing impact, scratch, and graffiti resistance of Bobrick Duraline Series Compact Grade Laminate partitions.
Key shown scratching Bobrick Duraline Series toilet partition surface to demonstrate scratch resistance.
Hammer shown impacting Bobrick 1082G toilet partition to demonstrate impact resistance.
Arm spraying water on Bobrick Duraline Series toilet partitions to demonstrate waterproof durability.

Description

Bobrick 2082.67 Series Toilet Partitions

Product Overview

The Bobrick 2082.67 Series is an overhead-braced, maximum-privacy toilet partition system from Bobrick’s DuraLine Series. Designed for demanding commercial and institutional environments requiring superior durability, privacy, and vandal resistance.

Key Specifications

Material Construction

  • Core Material: Compact Grade Laminate (CGL)
  • Thickness: Stiles and doors 3/4″ (19mm), panels 1/2″ (13mm)
  • Surface: Matte-finish melamine with colored face sheets and black phenolic-resin core
  • Fire Rating: ASTM E 84 Class A or Class B compliant

Hardware Features

  • Material: Type-304 stainless steel with satin finish
  • Security: Theft-resistant Torx screws with pin-in-head design
  • Installation: Factory-installed threaded inserts
  • Hinges: Self-closing, adjustable heavy-gauge 18-8 stainless steel
  • Emergency Access: Lift-to-release latch system

Privacy and Configuration

  • Privacy Level: Maximum privacy design (indicated by .67 suffix)
  • Mounting: Overhead-braced system for stability
  • Hardware Type: Institutional-grade for high-traffic use

Dimensions

  • Doors: 22-37″ wide × 71¾” high (559-940mm × 1822mm)
  • Panels: Up to 84″ wide × 71¾” high (2134mm × 1822mm)
  • Panel Width Limit: 60″ (1524mm) recommended for structural integrity

ADA Compliance

  • Operation: One-hand operation, no tight grasping required
  • Force Requirement: Maximum 5 pounds (22.2N) activation force
  • Standards: Meets ADA Sections 404.2.7 and 309.4

Installation Requirements

  • Primary Mounting: Overhead-braced (no ceiling/floor anchors for every component)
  • Wall Support: Requires wall backing for brackets
  • Floor Anchoring: Optional, requires 2″ (50mm) penetration into 3″ (75mm) concrete minimum

Warranty Coverage

  • General Warranty: 1 year against defects in materials and workmanship
  • CGL Extended Warranty: 25 years limited warranty for DuraLine Series Compact Laminate

Performance Benefits

  • Durability: Exceptional resistance to scratches, moisture, impact, and graffiti
  • Security: Vandal-resistant hardware and theft-deterrent fasteners
  • Maintenance: Low-maintenance CGL surface suitable for high-traffic areas
  • Environment Suitability: Ideal for wet environments and institutional use

Target Applications

Commercial facilities, educational institutions, public restrooms, healthcare facilities, and any high-traffic environment requiring maximum privacy and durability.

Key Differentiators

The .67 series designation indicates maximum privacy configuration with overhead bracing, distinguishing it from standard partition systems through enhanced privacy features and institutional-grade hardware components.
